Tight spaces and narrow corridors are a reality in the world of wheelchair users, yet they do not necessarily have to be an obstacle. With the right wheelchair you can maneuver around tight corners and down narrow corridors. Here is a list of the best narrow wheelchairs for tight doorways and spaces.
But which of the many wheelchairs would you choose? And which features should it have to make things easier. Here are a couple of pointers to consider.
What Is The Width Of A Normal Wheelchair?
An average wheelchair can have a width of up to 32 inches, with most being in the 21 to 30-inch range. In some cases, the seat cushion itself will measure up to 30 inches in width, meaning that the entire width of the wheelchair can be more than 32 inches. It is common to have the wheelchair up to 10 inches wider than the cushion. With electric wheelchairs the width can extend up to 40 inches or more depending on the weight of the user.
Do Wheelchairs Fit Through Standard Doorways?
These days, the standard width of a doorway is about 32 inches, with many doorways going up to a width of 36 inches. However, there are a decent number of doors that fall on the lower end in width, from 23 to 28 inches, and some even smaller. Older buildings tend to have narrower doorways which can be a real problem for wheelchair users.
How Wide Should A Doorway Be For A Wheelchair?
If you look at the answers of the above two questions, then you will realize that the problem we face is that the wheelchair width and the average doorway are a bit too close for comfort.
According to the ADA accessibility standards, the minimum distance that is acceptable from the face of the door to the other end of the door frame is 32 inches, which coincides with the width of a standard doorway. However, it is important how you take the measurement.
The measurement cannot just be the width of the gap in the wall as if there was no door. The illustration below, taken from the ADA website, explains it clearly.
4.13.5 Clear Width. Doorways shall have a minimum clear opening of 32 in (815 mm) with the door open 90 degrees, measured between the face of the door and the opposite stop.
Remember that this information pertains to the average wheelchair size. Narrower wheelchairs will have better results.
The Best Wheelchair Features To Keep In Mind
Many of the features you will encounter when navigating narrow spaces also come in handy when storing your wheelchair. The smaller, maneuverable, and lighter it is, the easier it is to store.
Removable And Lightweight
A model that is transportable and narrow is better since transport wheelchairs are naturally smaller and thus able to maneuver through small spaces.
Adjustable arms are always a great idea since they will allow you to squeeze through smaller spaces if the need arises by lowering or removing them. Some wheelchairs have swing away armrests or leg rests, which also contribute to space saving.
Size Of The Cushion
The size of the cushion is also an important factor when choosing a wheelchair. Remember, the size of the cushion is not the same as the width of the wheelchair.
If you would like to fit through a standard 32-inch door, then your cushion size should not be more than 22 inches. In fact, should you want to go through a narrower doorway of 28-inches, you should look at cushion sizes of between 16 and 18 inches.
Normally, the wheelchair width tends to be 8 inches wider than the cushion size. However, not all wheelchairs have this ratio, and some tend to have a smaller difference.
The Best Narrow Electric Wheelchairs
|
Make |
Model |
Width |
Turning Radius |
![]() |
FreeRider |
Luggie Chair |
23 inches |
30 inches |
![]() |
Pride Mobility |
Jazzy Passport |
23.50 inches |
24.25 inches |
![]() |
E-Wheels |
EW-M45 |
23.50 inches |
31 inches |
1. FreeRider Luggie Chair Foldable Power Chair
The Freerider Luggie is a folding, lightweight power wheelchair with a width of 23 inches and a turning radius of 30 inches. It has height and width adjustable armrests, and the seat is 17 inches wide. Without the battery and armrests, it has an overall weight of 70 pounds.
It has a maximum speed of 4.5 mph, ground clearance of 3.5 inches, a driving range of up to 22 miles and a weight capacity of 320 pounds. It has 3-inch by 8-inch PU solid tire drive wheels and 1.5-inch by 7-inch PU solid tire casters.
Do you love traveling but hate being bogged down by bulky mobility aids? Meet the perfect solution: a unit made specifically for airline travel. You can take it with you wherever you go, and it's approved by all airlines. The best part? It charges in just 90 minutes, so you don't have to wait around for it to be ready when you're in a hurry.
With a fully charged battery, this mobility aid can take you up to 8 miles. And when you're done using it, folding it up is simple with just a few steps. Once it's folded, you can pick it up by the footrest and wheel it behind you like a piece of luggage.
And if you're concerned about reliability, you can trust the FreeRider mobility scooter brand, one of the industry's leading mobility product manufacturers. Plus, their incredible warranty means you can rest easy knowing you made a smart investment. Travel smarter, not harder, with this amazing travel-friendly unit.
Pros:
- A turning radius of 30 inches
- Airline approved
- Charges in just 90 minutes
- A driving range of up to 8 miles
- Has an overall weight of just 70 pounds
- Folds together like a carry on suitcase
- Auto-folds with a push of a button
Cons:
- No storage space on model
- Limited use in rough terrain like grass and gravel
- Struggles to climb steep curbs
2. Pride Jazzy Passport Folding Power Chair JZPASS
The Pride Jazzy Passport is also a lightweight foldable power wheelchair. It is 23.50 inches wide and has a turning radius of 24.25 inches. The seat is 17.5x16.5-inches in dimension and is made from a strong and durable black foam type of material. The total weight without batteries is 59.8 pounds.
It has a maximum speed of 3.6 mph, ground clearance of 3 inches at the motor, a driving range of up to 7.9 miles and a weight capacity of 250 pounds. It comes with 11.25-inch perforated drive wheels and 8-inch solid casters.
Are you tired of traveling with limited storage for your belongings? Look no further than the Jazzy Passport power wheelchair - it offers various storage options to make your journey stress-free. Plus, it's FAA and TSA approved for personal mobility devices, ensuring your safety on flights.
And don't worry about leaving your lithium battery behind, as it's removable and can be placed in your carry-on. This unit, designed by Pride Mobility, even offers a one year in-home service warranty for added peace of mind. Upgrade your travel game with the Jazzy Passport.
Pros:
- Weighs only 53 pounds
- A weight capacity of 250 pounds
- A driving range of up to 7.9 miles
- FAA and TSA approved for personal mobility devices
- Comes with a one year in-home service warranty for added peace of mind
Cons:
- Limited storage space on model
- Not designed for driving on rugged terrain
- No headrest
3. E-Wheels EW-M45 Folding Power Wheelchair
Last on our list of narrow power wheelchairs is the EW-M45 by E-Wheels. This powerchair is designed with travel in mind, is lightweight and can fold. It has a width of 23.50 inches. The seat is 19 inches wide and 17 inches deep. It weighs just 59 pounds with batteries.
It has a maximum speed of 3.7 mph, ground clearance of 3 inches at the motor and a weight capacity of 400 pounds. It comes with 8-inch solid front wheels and 12.5-inch solid rear wheels.
The range on this unit is almost double of other comparable units on the market today, clocking in at 15.5 miles!
With a turning radius of 31 inches, navigating through tight spaces and corners is effortless with this unit. Plus, it's equipped with 8-inch front wheels and 12-inch rear wheels, enabling you to tackle both indoor and outdoor terrain with ease, even on uneven surfaces.
This electric folding wheelchair is not only reliable but is also backed by an EWheels warranty. If you encounter any product-specific issues, don't sweat it, as dedicated technical support is just a phone call away.
Pros:
- A total weight of just 59 lbs
- 15.5 mile range on this compact unit
- A weight capacity of 400 pounds
- Intuitive joystick controller to ensure you safely get around
- Folds up snuggling into a carry on luggage sized unit
- Comes with a back storage pocket
Cons:
- No headrest
- Not designed for driving in rugged terrain
- Will struggle to climb steep curbs
Conclusion
We hope you liked our review of these narrow power wheelchairs to help you easily slip through tight doorways and spaces. Please feel free to let us know if you have any questions or if you would like to see more of these types of articles to our site.
